主要用途
適用于中藥材的蒸、煮、燉、焯等加工.也可用于中藥的提取和濃縮以及食品、化工行業的釀造、消毒加工。

Main uses
Suitable to steam, boil and stew herb material, and it also can be used to extract, condense and disinfect in foods andchemical industries.

主要特點
易安裝、可傾斜、不污染產品、以蒸汽為熱源、鍋內及央層可分別進蒸汽、生產效率高，符合GMP要求。

Main technical characteristics
The machine is easy to install and tilt and will not cause any pollution to the herb materials. The gas goes through the pot and the mezzanine, thus it is high efficient.

主要技術參數 Main technical parameter

型號 Type	全容積 total volume (m³)	工作壓力 working pressure (MPa)	工作溫度 working temperature (℃)	外形尺寸 dimension (mm)	整機重量 weight (kg)
GZZ1000	1	<0.25	<139	2260x1210x1520	650
GZZ500	0.5	<0.3	<143	2230x1206x1020	430
GZZ300	0.3	<0.3	<143	1950x1006x1010	260
